Architecting Enterprise
IT & Security Infrastructure
From Surveillance Solutions & AI Analytics to Structured Cabling, Wireless Networks, and 24/7 Managed IT Services — powered by our certified DBOT Framework.
13 Core Service Pillars
Engineered for resilience, high bandwidth, and 24/7 reliability. Each pillar includes full technical specs, CAD designs, and image galleries.
Surveillance & CCTV Asset
IP Camera array installed at Tarlac City Command Center — 4K dome and PTZ units
Surveillance Solutions
End-to-end CCTV system design, deployment, and 24/7 maintenance across wired and wireless infrastructure.
- CCTV System Setup & Architecture
- Digital IP & Ultra-HD Analog Cameras
- Proactive Repair & Preventative Maintenance
Structured Cabling Asset
Organized patch panel and rack cabinet after JHXTES cable rehabilitation — Cat6A runs
Structured Cabling Solutions
High-performance copper horizontal cabling, fiber backbone installation, termination, testing, and cabinet rehabilitation.
- Copper Horizontal & Vertical Cabling
- Cable Trunking & Cabinet Rehabilitation
- High-Precision Termination & Fluke Testing
Network & Wireless Asset
Enterprise core switch rack and wireless access point deployment — Wi-Fi 6 multi-floor setup
Network Solutions & Security
Robust LAN architecture, IP Radio microwave links, enterprise wireless LAN, and next-gen network security.
- Enterprise LAN & Core Switch Architecture
- IP Radio & Microwave Long-Distance Links
- Network Security, Firewalls & VPN Gateways
Telephony & IP-PBX Asset
IP-PBX server and SIP desk phone deployment in a corporate contact center environment
Telephony & Unified Communications
Integrated contact center solutions, IP/Analog/Digital PABX systems, and VoIP communication channels.
- Contact Center Infrastructure & Agent Queues
- Analog, Digital & IP Phone Deployments
- IP-PBX & Hybrid PABX Server Setup
Smart Door Locks Asset
UL10C fire-rated smart door lock installed on a server room entry — RFID + PIN credential
Electronic Door Lock Solutions
Centralized access management featuring real-time wireless control, multi-ID tech, and UL10C fire resistance.
- Centralized Multi-Door Access Management
- Wireless Real-Time Status & Audit Logging
- UL10C Compliant Fire-Resistant Locks
AI Vision & Analytics Asset
AI analytics dashboard showing live ANPR license plate detection and heat map overlays
CCTV with AI Analytics
Next-gen AI camera surveillance: Facial recognition, people counting, thermal scanning, LPR, and perimeter intrusion.
- AI Facial Recognition & Watchlist Alerts
- Bi-Directional People & Vehicle Counting
- License Plate Recognition (ANPR / LPR)
FDAS Systems Asset
Addressable FDAS control panel and smoke detector installation in a commercial building
Fire Detection & Alarm System (FDAS)
Addressable and conventional fire alarm installations, smoke detectors, pull stations, and emergency warning horns.
- Addressable & Conventional FDAS Control Panels
- Optical Smoke & Rate-of-Rise Heat Detectors
- Manual Break-Glass Pull Stations & Strobes
Access Control Asset
Biometric facial recognition terminal at a corporate HQ entry — multi-factor access control
Access Control Systems
Biometric fingerprint, face recognition, RFID card readers, and centralized time-attendance management software.
- Biometric Fingerprint & 3D Face Verification
- RFID Contactless Smart Card Readers
- Time & Attendance Shift Software Integration
Boom Barriers Asset
Heavy-duty boom barrier gate with UHF RFID reader at a subdivision entrance — hands-free entry
Parking Boom Barriers
Automated high-speed vehicle barrier gates, loop detectors, RFID long-range tags, and ticketing systems.
- High-Speed Automatic Boom Barrier Arm
- Long-Range UHF RFID Reader (Up to 10m)
- Safety Ground Loop & Infrared Anti-Smash
X-Ray Scanners Asset
Dual-energy X-ray baggage scanner at a government checkpoint — color-coded organic/metal separation
X-Ray Baggage Scanners
Dual-energy X-ray screening machines for luggage, parcels, and cargo with organic/inorganic color identification.
- Dual-Energy X-Ray Imaging Generator
- Organic / Inorganic Material Color Separation
- Threat Image Projection (TIP) Training System
Metal Detectors Asset
33-zone walkthrough metal detector archway at a shopping mall entrance — LED threat zone display
Walkthrough Metal Detectors
Multi-zone walkthrough detection archways with LED zone positioning, sensitivity tuning, and pass-through counters.
- 18 to 33 Pinpoint Detection Zones
- Dual LED Column Displays Showing Threat Location
- Adjustable Sensitivity (0 to 999 Levels)
Turnstiles & Gates Asset
Optical flap speed gate turnstiles in a corporate lobby — stainless steel with LED indicators
Turnstiles & Pedestrian Speed Gates
Tripod turnstiles, flap barriers, and optical speed gates integrated with access readers and emergency auto-drop.
- Tripod Turnstile Gates with Auto-Drop Arm
- Optical Acrylic Flap & Swing Speed Gates
- Anti-Tailgating & Anti-Reverse Entry Sensors
Managed IT Services Asset
JHXTES technician performing server rack maintenance and preventative hardware cleaning on-site
Managed IT Services & Support
Comprehensive computer repair, server maintenance, backup & recovery, website dev, and dedicated onsite SLA support.
- Computer, Laptop & Server Hardware Repair
- Automated Data Backup & Disaster Recovery
- Full IT Outsourcing & Remote Service Desk
Enterprise Architecture Infographics
Visual schematics mapping out our end-to-end IT lifecycle methodology and converged security ecosystem.
DBOT Lifecycle Flowchart
Design → Build → Operate → Transfer
DBOT Methodology Blueprint
Upload high-res diagram showing the 4 lifecycle execution phases.
Converged IT Topology Map
CCTV • Fiber LAN • AI Vision • Cloud SLA
Converged Security & IT Topology
Upload network schematic connecting core switches, NVR, AI cameras, and gates.
The JHXTES DBOT Framework
Design → Build → Operate → Transfer. Our end-to-end methodology guarantees accountability from initial blueprinting to post-handover ownership.
Design
Architecture & Blueprinting
We analyze client requirements, conduct site surveys, and engineer tailored IT and security blueprints adhering to global technical standards.
Build
Procurement & Deployment
Our certified engineering team executes physical installation, structured cabling, hardware mounting, network configuration, and system commissioning.
Operate
24/7 Monitoring & SLA Support
We provide round-the-clock remote monitoring, preventative maintenance, rapid troubleshooting, and technical help desk SLA response.
Transfer
Knowledge & Full Ownership
We train client personnel, hand over comprehensive system documentation, and transfer complete operational control with full warranty backing.
Proof of Work & Case Studies
Real-world municipal command centers, barangay public safety networks, and commercial store installations.
Tarlac City Municipal CCTV & Command Center Proof Photo
Transformed municipal public safety monitoring with real-time incident tracking and rapid dispatch capability.
Tarlac City Municipal CCTV & Command Center
"Transformed municipal public safety monitoring with real-time incident tracking and rapid dispatch capability."
City-wide digital IP surveillance network and centralized 24/7 emergency control room deployment equipped with AI License Plate Recognition and video wall matrix.
Barangay Wired Public Safety CCTV Network Proof Photo
Empowered local community leaders with high-definition video evidence and round-the-clock perimeter security.
Barangay Wired Public Safety CCTV Network
"Empowered local community leaders with high-definition video evidence and round-the-clock perimeter security."
Comprehensive barangay-wide outdoor CCTV setup using heavy-duty weatherized poles, optical fiber horizontal cabling, and local monitoring station.
Commercial Store Outlets & Mall Installations Proof Photo
Standardized IT and security deployment across retail branches, cutting inventory shrinkage and enhancing customer analytics.
Commercial Store Outlets & Mall Installations
"Standardized IT and security deployment across retail branches, cutting inventory shrinkage and enhancing customer analytics."
Integrated surveillance, electronic access control, and structured cabling for multi-branch retail stores and commercial establishments.
Schedule a Free Site Survey & Engineering Assessment
Our certified engineers will analyze your cabling, surveillance, or network bottleneck and deliver a detailed DBOT proposal within 48 hours.
